Raspberry Pi Global Shutter Camera – C-mount Maximize

Raspberry Pi Global Shutter Camera – C-mount

The new High Quality camera from Raspberry Pi - lens not included!

More details

Availability: On_stock

59,95 €

This is the Raspberry Pi Global Shutter Camera. It is a 1.6-megapixel camera from Raspberry Pi. This type of camera doesn't exhibit the typical artifacts of rolling shutter cameras, making it ideal for fast-motion photography and machine vision applications. Even small distortions can affect inference performance.

The Global Shutter Camera features a large pixel size of 3.45 μm × 3.45 μm, ensuring high light sensitivity. This is beneficial for high-speed photography as it allows for short exposure times. The camera incorporates a 1.6MP Sony IMX296 sensor and the same C/CS-mount lens assembly as the Raspberry Pi HQ Camera, making it compatible with a wide range of lenses.

The IMX296 has lower resolution compared to rolling shutter sensors of similar size, which is advantageous for machine vision applications. Higher-resolution images can be challenging to process in real-time. With the right lens magnification, the lower resolution of the Global Shutter Camera can capture an image suitable for machine vision model processing.

The Raspberry Pi Global Shutter Camera includes the following accessories: one C- to CS-mount adapter, screwdriver, 150mm flex cable, and a removable plastic back for protection. It is compatible with any Raspberry Pi computer that has a CSI connector.

This camera comes with a cable for the Raspberry Pi 1, 2, 3 or 4. For the Raspberry Pi Zero and Zero2W you need the adapter cable for the Raspberry Pi Zero. For the Raspberry Pi 5 you need the adapter cable for the Raspberry Pi 5. These are not supplied as standard.

Specifications for the Raspberry Pi Global Shutter Camera:

  • Dimensions: 38 × 38 × 19.8mm (29.5mm with adapter and dust cap)
  • Weight: 34g (41g with adapter and dust cap)
  • Sensor: Sony IMX296LQR-C
  • Resolution: 1.58 megapixels (color)
  • Sensorformat: 6.3 mm sensordiagonal
  • Pixel Size: 3.45μm × 3.45μm
  • Output: RAW10
  • Back focus length of the lens: Adjustable (12.5-22.4mm)
  • Lensmounts:
    • CS-Mount
    • C-Mount (C-CS adapter meegeleverd)
  • IR-filter: Integrated
  • Length flex-kabel: 150mm
  • Accessoires:
    • C-CS mount adapter
    • Screwdriver
    • Tripod mount: 1/4"-20
  • Compliance:
    • FCC 47 CFR Part 15, Subpart B, Class B Digital Device.
    • Electromagnetic Compatibility (EMC) 2014/30/EU
    • Restriction of Hazardous Substances (RoHS) Directive 2011/65/EU

Production Duration: The Raspberry Pi Global Shutter Camera will remain in production at least until January 2032.
